Image Display
|
|
| Projector Display System |
0.8″ Poly-silicon LCD x3
|
| Native Resolution |
XGA (1024 x 768)
|
| Number of Pixels |
786,432 x3 = 2,359,296
|
| Lumens Brightness |
5000 ANSI Lumens
|
| Contrast Ratio |
1000:1
|
| Aspect Ratio |
4:3 native, Supports 16:9
|
| System |
NTSC, NTSC 4.43, PAL, PAL-M, PAL-N and SECAM
|
| HDTV Compatibility |
Displays 480i, 480p, 525i, 525p, 720p and 1080i HDTV resolution at standard definition
|
Lens System
|
|
| Lens |
F:1.7-1.9 (f=24 – 29mm)
|
| Focus/Zoom Adjusting |
1:2:1 Manual zoom
|
| Lens Shift |
1:1 to 9:1 (vertical); 6:4 to 4:6 (horizontal)
|
| Recommended Projection Size |
From 30 up to 350″ diagonal
|
Features
|
|
| Keystone Correction |
Vertical +/-40°, Horizontal +/-20°
|
| Ceiling Mountable |
Yes
|
| Rear Screen Projection |
Yes
|
| Projection Tilt Option |
Yes
|
| Built-In Speaker |
4W SRS WOW Technology x4
|
Input/Output Connectors
|
|
| Input Terminals |
Computer – HD-15 RGB – VGA (15 pin) x1 -HDMI x1
Video – S-Video: 4 pin x1 – Composite: RCA x1 – Component: BNC x5 – Component: RCA x3
Audio – Stereo mini jack x2 – RCA (R/L) x2
|
| Output Terminals |
HD-15 RGB – VGA (15 pin) x1, Audio: Stereo mini jack x1
|
| Control Protocol |
USB for remote control mouse
RS-232C
Wired LAN: RJ-45
Wireless LAN: SD wireless card 802.11b/g
SD Card Slot
USB Slot for jump drive
|
General
|
|
| Lamp (Bulb) |
275W UHB
2000-hour Life expectancy
Whisper mode: 3000-hour Life
(Depending on conditions)
|
| Fan Noise |
Normal mode: 39dB
Whisper mode: 33dB
|
| Remote Control |
Full function
|
| Power Requirements |
460W, 100 – 120V/220 – 240V AC, 50/60Hz
|
| Dimensions |
16.5 x 5.5 x 12.6″ (418 x 139 x 319mm)
|
| Weight |
15.8 lbs (7.19kg)
|
